Gems Pressure Sensor

Gems Pressure Sensor

Product Details:

  • Product Type Gems Pressure Sensor
  • Material Stainless Steel
  • Output 4-20 mA
  • Weight 50-100 Grams (g)
  • Warranty 1 Year
2000 INR/Unit
X

Price And Quantity

  • 2000 INR/Unit
  • 1 Unit

Product Specifications

  • 1 Year
  • 4-20 mA
  • Gems Pressure Sensor
  • Stainless Steel
  • 50-100 Grams (g)

Trade Information

  • Cash Advance (CA)
  • 1 Days
  • All India

Product Description

We are actively engrossed in supplying Gems Pressure Sensor that is used in a range of applications. It is used in a range of applications including vehicles, robotics transportation, semiconductor, and general industries. Owing to its reliable performance, longevity, and resilience, it is preferred by our customers. Gems Pressure Sensor does not degrade in quality or become inferior in the long run. Our customers can approach us to purchase the pressure sensor at a budget-friendly price.

3100 Series and 3200 Heavy Duty Series

Compact OEM Pressure Transmitters



  • Exceptional Long Term Stability
  • 0-100 psi to 0-30,000 psi Ranges (0-7 bar to 0-2,200 bar)
  • High Proof Pressures with All Stainless Steel Wetted Parts
  • Broad Choice of Outputs, Electrical Connectors, and Pressure Ports
  • Dual Pressure and Temperature Sensing option



Specifications :

Performance


Long Term Drift

0.2% FS/YR (non-cumulative)

Accuracy

3100

0.25% FS

3200

0.25% FS for >1000 psi (60 bar)
0.50% FS for <1000 psi (60 bar)

Thermal Error


3100

0.83% FS/100°F (1.5% FS/100°C)

3200

2% FS/100°C for <1000 psi (60 bar)

Compensated Temperatures

-40°F to +257°F (-40°C to +125°C)

Operating Temperatures

-40°F to +257°F (-40°C to +125°C) for elec. codes B, C, E, G, 6, 8, 9, Y

-5°F to +180°F (-20°C to +80°C) for elec. codes F, 3, W

Zero Tolerance

3100

0.5% of span

3200

0.50% of span for >1000 psi (60 bar)
1.00% of span for <1000 psi (60 bar)

Span Tolerance

3100

0.5% of span

3200

0.50% of span for >1000 psi (60 bar)


1.00% of span for <1000 psi (60 bar)

Response Time

1 ms

Fatigue Life

Designed for more than 100 M cycles

Mechanical Configuration Pressure Port

See under "How to Order,” last page

Wetted Parts

17-4 PH Stainless Steel

Housing

304 Stainless Steel

Electrical Connection

See under "How to Order,” last page

Enclosure

IP67 (IP65 for electrical codes G & W)

Vibration

40G peak to peak sinusoidal, (Random Vibration: 20 to 1000 Hz @ approx. 40G peak per MIL-STD-810E)

Shock

Withstands free fall to IEC 68-2-32 procedure 1

EMC (Radiated Immunity)

100 V/m

Approvals

CE, conforms to European Pressure Directive,


Fully RoHS compliant, CRN Registered to ANSI/ASME B31.3,


UL recognized files # E219842 & E174228

Weight

1.8 - 5.3 ounces (50 - 150 grams). Configuration dependent.

Voltage

Output (3-wire)

0 V min. to 10 V max. See under "How to Order," last page

Supply Voltage

2 Volts above full scale to 30 VDC max @ 4.5 mA (6.5 mA on dual output version)

Source and Sinks

2 mA

Current Output (2-wire)

4-20 mA

Supply Voltage

8-30 VDC

Maximum Loop Resistance

(Supply Voltage-8) x 50 ohms

Ratiometric Output

0.5 to 4.5 VDC @ 4 mA (6.5 mA on dual output version)

Supply Voltage

5 VDC +10%
